Genie Z-20/8N Narrow Electric Boom Lift - 3' 11" Wide - 26’ Working Height

1997 Genie Z-20/8N Articulating Boom Lift

Type: Electric Articulating Boom | Max Platform Height: 20 ft | Max Reach: 8 ft 8 in

Professional Overview

The Genie Z-20/8N is a compact, electric-powered articulating boom lift designed specifically for indoor maintenance and construction. The "N" stands for Narrow, highlighting its slim 3-foot-11-inch chassis that allows it to pass through standard doorways and navigate tight warehouse aisles. Its 1982-era design remains popular for its simplicity and 180° rotating jib, which provides "up-and-over" reach that standard scissor lifts cannot match.

Technical Specifications

• Working Height: 26 ft (Platform height: 20 ft)
• Horizontal Reach: 8 ft 8 in
• Up & Over Clearance: 16 ft 1.5 in
• Lift Capacity: 400 lbs (ANSI/CSA)
• Power Source: 48V DC (Eight 6V, 245-255 Ah batteries)
• Tires: Solid rubber, non-marking (18 x 14 x 6 in)
• Total Weight: Approx. 11,000 lbs (Note: Unit weight is heavy due to battery counterweights)

Key Performance Features

• Zero Tailswing: Designed to work in confined areas without the rear of the turntable swinging out into traffic or shelving.
• Proportional Controls: Offers smooth, incremental movement for high-precision positioning near sensitive equipment.
• Battery Counterweight System: The batteries are strategically placed to act as the machine's counterweight. Warning: Replacing batteries with lighter alternatives can compromise the machine's stability and cause tip-overs.
• 48V Electric Drive: Provides quiet, emission-free operation, making it ideal for schools, hospitals, and food-grade warehouses.
