Gorbel 26' x 45' Twin-Bridge Freestanding Crane w/ (2) Schmalz JumboFlex 50 Vacuum Lifters (2021)
Gorbel 26' x 45' Twin-Bridge Freestanding Crane w/ (2) Schmalz JumboFlex 50 Vacuum Lifters (2021)
$21,900 (USD)
Available quantity:1
or
Call 414 841 4377
Description
High-Capacity Ergonomic Workstation
Gorbel Twin-Bridge Crane System & Dual Schmalz JumboFlex 50 Lifters
This integrated solution combines the industry’s most "frictionless" bridge crane with the gold standard in vacuum lifting. Designed for high-cycle logistics and heavy manufacturing, this 2021-series system offers a massive 1,170 sq. ft. coverage area.
1. Structural Components: Gorbel Freestanding Crane
- System Capacity: 500 lbs (113 kg) — (Dual 250 lb Bridges)
- Runway Length: 45' (Three 15' modular sections).
- Bridge Span: Dual (2) 26' Bridges.
- Support Structure: Freestanding "Bolt-Together" design (requires no building column support).
- Track Type: Cold-rolled high-strength steel for industry-leading 100:1 productivity ratio.
- Twin-Bridge Advantage: Allows two independent operators to work simultaneously within the same 45' footprint without interference.
2. Lifting Components: (2) Schmalz JumboFlex 50 (2021 Units)
- Lift Capacity: 50 kg (110 lbs) per unit.
- Operating Unit: Ergonomic one-handed "Flex" trigger control.
- Lift Tube: 120 mm diameter heavy-duty bellows with protective textile sleeve.
- Rotation: Integrated 360° continuous swivel at the connection head.
- Quick-Change: Integrated tool-free adapter for swapping suction grippers.
3. Technical Specifications (Per Unit)
Model Year: 2021
Max Lift Speed: 197 ft/min (60 m/min)
Vacuum Generator: EVE-TR 50 AC3 (1.5 kW / 60 Hz)
Suction Rate: 60 $m^3/h$
Safety Integrated: Non-return valve for power-loss load retention
Filtration: STF Dust Filter included
Investment Summary
This system is ideally suited for palletizing/depalletizing, baggage handling, or sheet metal/wood panel movement. Because the crane structure is rated for 250 lbs, it provides an incredibly stable platform for the 50 kg Schmalz units, eliminating the "bounce" often found in lighter-duty aluminum or undersized rails.
- Condition: 2021 Manufacturing Date; Excellent operational status.
- Footprint: 26' x 45' (Modular/Adjustable).
Specifications
| Manufacturer | Gorbel |
| Model | 250# Freestanding Bridge Crane System w/Vacuum Lifts |
| Year | 2021 |
| Condition | Used |
| Stock Number | J19-8 |
| 1. STRUCTURAL COMPONENTS | GORBEL FREESTANDING CRANE |
| * Bridge Span | Dual (2) 26' Bridges. |
| MAX LIFT SPEED | 197 FT/MIN (60 M/MIN) |
| MODEL YEAR | 2021 |
| SUCTION RATE | 60 $M^3/H$ |
| FILTRATION | STF DUST FILTER INCLUDED |
| * Footprint | 26' x 45' (Modular/Adjustable). |
