Armil C.F.S Model 10431 Refurbished Armil Dewax Pusher Furnace

Armil C.F.S. Model 10431 Refurbished Dewax Pusher Furnace High-Volume Continuous Production | 2100°F Capability | Precision PLC Control

Armil C.F.S. Model 10431 is the industry standard for high-efficiency investment casting operations. Unlike standard box furnaces, this Pusher-style system allows for continuous mold processing, significantly reducing energy consumption and labor costs. The "Pusher" design advances molds through the chamber on a timed cycle, ensuring every shell receives identical heat exposure for a flawless burnout and preheat.

This unit has been fully refurbished, featuring a renewed refractory lining and an updated control package to meet modern NADCAP and AMS2750 standards. Engineered with an integral incineration design, the Model 10431 often utilizes the furnace chamber itself to burn out residual wax, potentially eliminating the need for a separate afterburner system.

• Automated Throughput: Heavy-duty pusher system allows for "set and forget" production, moving trays seamlessly from the loading zone to the exit.
• Thermal Efficiency: Utilizing premium American-made Fiberfrax lining for rapid heat-up and minimal exterior shell temperature.
• Precision Controls: Refurbished with a modern PLC/HMI interface for real-time temperature tracking and recipe management.
• Wax Recovery Ready: Specifically designed to handle the high-carbon environment of dewaxing without fouling the burner systems.
• Rugged Construction: Built on a heavy-duty steel frame designed to withstand the 24/7 rigors of a foundry environment.
• Manufacturer: Armil C.F.S • Model # : 10431
• Year of Manufacture : 2003
• Furnace was completely relined with new high-end refractory in 2025
• Exterior entirely repainted with high temperature paint
• Hydraulics for the pusher and pump were rebuilt bythe manufacturer
• Furnace sale also includes:
• Pusher unit • Conveyors for both entrances
• Thirty (30) trays for inside the oven
• Control Panel
• Spare burner

Technical Specifications

• Furnace Type: Continuous Pusher (Single or Multi-row configuration).
• Application: Investment casting dewaxing, burnout, and mold preheating.
• Operating Temperature: Typically 1650°F – 2100°F (Standard Armil range).
• Temperature Uniformity: +/- 25°F at thermal equilibrium.
• Push Mechanism: Hydraulic or Electro-Mechanical pusher head.
• Refractory Lining: High-efficiency Fiberfrax ceramic fiber (standard 6"–9" thickness).
• Control System: Allen-Bradley PLC with a color touchscreen HMI (if modernized during refurbishment).
• Burner System: Low NOx high-velocity burners with Honeywell or Siemens flame supervision.
•
